HFP1500 High Frequency Probe
24 922252-00 Rev A
3. Turn on the other test equipment and allow these to warm up for the time recommended
by the manufacturer.
4. While the instruments are reaching operating temperature, make a photocopy of the
Performance Verification Test Record (located in Appendix A), and fill in the necessary data.
5. Select the channel to which the probe is connected. Set the oscilloscope scale factor to
20mV/div.
6. Disconnect the ProBus Extender Cable from the oscilloscope. Verify that the scale factor
changes from 20 mV/div to 2 mV/div.
7. Re-connect the ProBus extender Cable to the oscilloscope.
NOTE: The correct operation of the HFP1500 controls requires software version 8.7.0 or higher on
LC series oscilloscopes. The software version in the test oscilloscope can be verified by pushing
SCOPE STATUS, then selecting the System menu option.
Functional Check
The functional check will verify the basic operation of the probe functions. It is recommended the
Functional Check be performed prior to the Performance Verification Procedure.
1. Return to the factory default settings by:
a. Pressing the oscilloscope’s front panel PANELS button.
b. From the Menu buttons press FROM DEFAULT SETUP.
2. Select Channel 1 and enter the Coupling menu.
3. Verify that Probe sensed (HFP1500) is displayed on the right hand menu.
4. If the trace colors have been reassigned or you are unsure, restore the default colors by
pressing the following menus: DISPLAY, More Display Setup, Color Scheme and in the Color
Scheme menu press 1.
5. Verify that the probe head LED shows basically the same color as the channel 1 trace color.
6. Disconnect the probe from channel 1 and connect respectively to channel 2, 3 and 4.
7. Verify that in each case the LED color corresponds to the trace color of the channel to which
the probe is connected.
