923129-00 Rev A

Trigger Control

7

Sets the trigger level
— push to set to 50%.

Is lighted when the
trigger is armed.

Is lighted and stays
lit after a trigger.

Triggers even
if the trigger
conditions are
not met.

Triggers
whenever
the trigger
conditions
are met.

Trigger Level

Indicator

Trigger Position

Indicator

Post

Trigger

Indicator

Trigger

Status

Trigger

Source

Trigger

Slope

Trigger

Mode

Trigger

Level

Trigger

Coupling

Triggers once
(single-shot
acquisition)
when the trigger
conditions are met.

Cancels the
acquisition in Auto,
Normal, or Single
trigger mode.

Press to select the
type of coupling
desired.

Selects the
trigger scan
feature.

Select the
channel to
trigger.

Select whether
to trigger on
the rising edge,
falling edge, or
either. More
options are
available in the
trigger setup
menu.

Touch to access the
trigger setup menu.

Press to open the
trigger setup menu.
