923129-00 Rev A

Setting Up Math

16

Math Setup

Touch Math in the top menu
and then touch Math Setup.

Choose Your Math Function
and Source

in the math setup

menu. Touch on a function
number (Fx) and select a math
function. Select the source in the
Fx tab, as required.

Make Setup Adjustments

using the right-hand menu. Touch the Zoom
tab and adjust zoom, or use the front panel
Horizontal and Vertical Controls to adjust
position and scale.
