4 cross input zones, 5 on-board relays, Cross input zones 4.15.5: on-board relays – System Sensor PDRP-2001 User Manual
Page 96
96
PDRP-2001 Series Manual — P/N 53043:E1 2/28/2011
Operating Instructions
Read Status
4.15.4 Cross Input Zones
Pressing 1 while viewing Read Status Screen #2 will display the following screens:
Pressing 1 for Release 1 or 2 for Release 2 will display the cross-zoning, if any, for the selected
Releasing Circuit as illustrated in the following screen:
The Cross Zone Release screen displays the zones that have been cross-zoned. In this example,
Zone 1 is cross-zoned with Zone 4.
4.15.5 On-Board Relays
Pressing 2 while viewing Read Status Screen #2 will display the following screen:
To view the information about a relay, press the number key corresponding to the desired relay.
The following screen will be displayed:
READ STATUS
1=CROSS INPUT ZONES
2=ON-BOARD RELAYS
3=SYSTEM SETTINGS
Read Status Screen #2
CROSS INPUT ZONES
1=RELEASE 1
2=RELEASE 2
Cross Input Zone Screen
CROSS ZONE REL 1
X 1 4
NONE
NONE
Cross Input Zone Screen
ON-BOARD RELAYS
1=RELAY 1
2=RELAY 2
3=RELAY 3
RELAY #
TYPE ALARM
LATCHING NO
