102 PDRP-2001 Series Manual — P/N 53043:E1 2/28/2011
Power Supply Calculations Calculating the System Current Draw
Table 5.3 contains three columns for calculating current draws. For maximum output current
available per circuit and per panel, refer to Section 1.2, “Specifications”, on page 13. For each
column, calculate the current and enter the total (in amperes) in the bottom row. When finished,
copy the totals from Calculation Column 2 and Calculation Column 3 to Table 5.4 on page 103.
Device Type
Calculation Column 1
Primary, Non-Fire Alarm Current
(amps)
Calculation Column 2
Secondary, Fire Alarm Current
(amps)
Calculation Column 3
Secondary, Non-Fire Alarm
Current
(amps)
Qty X [current draw]= Total Qty X [current draw] = Total Qty X [current draw]= Total
Main Circuit Board 1 X[0.095]= 0.095 1 X[0.221] 1, 2 = 0.221 1 X[0.095]= 0.095
CAC-5X [ ] X[0.001]= [ ] X[0.001]= [ ] X[0.001]=
4XTMF [ ]
(1 max.)
X[0.005]= [ ] X[0.011] 1 = [ ] X[0.005]=
ANN-SEC card [ ]
(1 max.)
X[0.003]= [ ]
(1 max.)
X[0.003]= [ ]
(1 max.)
X[0.003]=
ANN-80(C) [ ] X[0.037]= [ ] X[0.040]= [ ] X[0.015]=
ANN-I/O [ ] X[0.035]= [ ] X[0.200]= [ ] X[0.035]=
ANN-RLY [ ] X[0.015]= [ ] X[0.075]= [ ] X[0.015]=
ANN-(R)LED [ ] X[0.028]= [ ] X[0.068]= [ ] X[0.028]=
ANN-S/PG [ ] X[0.045]= [ ] X[0.045]= [ ] X[0.045]=
2-wire Detector
Heads
[ ] X[ ] 3 = [ ] 4 X[0.040= [ ] X[ ] 3 =
4-wire Detector
Heads
[ ] X[ ] 3 = [ ] 4 X[0.040]= [ ] X[ ] 3 =
Power Supervision
Relays 5
[ ] X[0.025]= [ ] X[0.025]= [ ] X[0.025]=
NAC #1 [ ] X[ ]=
NAC #2 [ ] X[ ]=
NAC #3
NAC #4
Current Draw from
TB9 (nonalarm)
[ ]= [ ]= [ ]=
Sum each column 6
for totals
Primary Non-Alarm = Secondary Alarm = Secondary Non-Alarm =
Table 5.3 System Current Draw Calculations
1 If using the Reverse Polarity Alarm output, add 0.005 amps; if using the Reverse Polarity Trouble output, add
another 0.005 amps.
2 The current shown represents one zone (IDC) on the main circuit board in alarm. One zone consumes 0.040
amps.
3 Refer to the Device Compatibility for standby current.
4 Enter the number of IDCs used minus one.
5 Must use compatible listed Power Supervision Relay.
6 Total current draw listed above cannot exceed 7.2 amps
