140 PDRP-2001 Series Manual — P/N 53043:E1 2/28/2011
Compatible Devices Notification Appliances For Canadian Applications
G.4.2 System Sensor SpectrAlert Advance
System Sensor Spectralert Advance chimes, chime strobes, horns, horn strobes and strobes base
models: CHR, CHW, CHSR, CHSW, HR, HW, P2R, P2W, P2RH, P2WH, P4R, P4W, P4RH,
P4WH, PC2R, PC2W, PC2RH, PC2WH, PC4R, PC4W, PC4RH, PC4WH, SCR, SCW, SCRH,
SCWH, SR, SW, SRH, SWH, SW-ALERT, SWH-ALERT, MHR,MHW followed by suffixes
denoting application (K=outdoor), market (A=Canada) and / or markings (P=Plain, SP=Spanish,
FR=French, B=Bi-lingual and PG=Portugese).
(UL 864 9th Edition)
G.5 Notification Appliances For Canadian Applications
• Refer to manufacturer’s installation instructions for more information.
• Contact manufacturer for current draws or additional options
G.5.1 System Sensor
G.6 Releasing Applications
MDLA / MDLWA Sync Modules, H24A, P1224MCA, P2415A, P241575A, P2475A, P24110A, PC2415A, PC241575A,
PC2430A, PC2475A, PC24115A, PC24177AS1224MCA, S2415A, S241575A, S2475A, SC24110A, SC2415A,
SC241575A, SC2430A, SC2475A, SC2495A, SC24115A, SC24177A,
SSM24-6A, SSM24-8A, SSM24-10A - Alarm Bells
CHWA, CHRA, HRA, HWA, SRA, SWA, SCRA, SCWA, SRHA, SWHA, SCRHA, SCWHA, P2RA, P2WA, PC2RA,
PC2WA, P4RA, P4WA, PC4RA, PC4WA, CHSRA, CHSWA
Manufacturer Model
Rated Current
DC Milliamps
Rated Voltage
DC Volts
Asco HV2740607 375 24
Asco HV2838521 375 24
Versa CGS-4232-NB3-S2 438 24
Snap-Tite 2823A-2NB-A4F6 458 24
Snap-Tite 2823A-2NB-A4F5 917 12
Kidde-Fenwal 890181 2000 24
Viking 11591 417 24
Viking 11595 417 24
Barnbrook Systems EA45 200 24
Honeywell/
Skinner
701X7028 917 24
TLX PA0036-A 600 24
Victaulic 753E 364 24
Victaulic 767 364 24
