Scope of this user guide, Designing a pipe network – System Sensor Pipe Installation User Manual
Page 3

User Guide: Aspirating Smoke Detector Pipe Installation
3
Scope of this user guide
The purpose of this user guide is to provide details on the physical installation of the pipe network for the FAAST Fire Alarm Aspiration
Sensing Technology
®
aspirating smoke detector. Local codes and regulations may vary and take precedence over the information
contained in this user guide.
Designing a Pipe Network
The FAAST detector and its pipe network allow deployment of smoke detection in challenging and mission critical environments. In
order to ensure the system will operate in accordance to site specific requirements, as well as local codes and regulations, the pipe
network must be designed and verified using the PipeIQ
®
software. PipeIQ can be downloaded at systemsensor.com/faast.
