FACEPLATE OPTIONS FACEPLATE OPTIONS
Your CDM-9100 phone’s faceplate is available in vari-
ous color options. Always use and store your phone
with the faceplate attached.
To Replace Faceplates
Screw
Hooks
2 1. Turn the phone off and remove
the battery pack. Disconnect
the phone from the AC Adapter
or any other device.
2. Unscrew a screw with a size
S Phillips-head screwdriver.
The screw stays on the phone.
3. Put a coin in a slot at top of
the phone and twist it.
4. Pull the top of the faceplate
forward to open it.
5. Hold the phone leaning on
your hand. Place the bottom of
the faceplate against the bot-
tom of the phone so that the
inner tabs fit the slots. Close
the faceplate and snap it shut.
Make sure that all seven hooks
are closed and all keys oper-
ate smoothly.
6. Tighten the screw.
Note: Prevent any dust or small
things going into the phone.
3
4 5
