Appendices
38
,QWHUOHDYHGRI
Encodable Character Set All 10 digits (0-9)
Data Character Density
11.11 CPI
(based on X = 0.010 (0.25 mm), 3:1)
Non-Data Overhead Equivalent to 1 data digit
Symbol Length Variable, Even number of digits
Check Digit One, Optional
USS Modulo 10
OPCC Modulo 10
Special Features Bearer Bars
Interleaved 2 of 5 Characteristics
Interleaved 2 of 5 (also called I 2/5 or ITF) is a bar code symbology with a numeric character set and unique start and stop
patterns. Interleaved 2 of 5 symbols always contain an even number of digits. In the symbol, two characters are paired together
using bars to represent the first character and spaces to represent the second. Each character has two wide and three narrow
elements. To enhance bar code integrity a check digit and Bearer Bars can be present.
0 1 2 3 4 5 6 7 8 9
Interleaved 2 of 5 - 13 Mil
0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9
Interleaved 2 of 5 with Bearer Bars - 13 Mil
