IAI America PS-24 - Manual (Page 17)

13
4. Basic Specifications
Specifications
Specification Item
100V AC Specification
PS241
200V AC Specification
PS242
Rated Voltage DC Output 24V
± 10% (fluctuates depending on duty)
Rated DC Current Output 8.5A
Peak Maximum DC Current
Output 17A
Rated Output Wattage 204W
Efficiency 80%
Rated Input Voltage
(frequency) 100 to 115V AC
(50/60Hz) 200 to 230V AC
(50/60Hz)
Input Voltage Range 90 to 125V AC 180 to 250V AC
Input Current 3.5A
(when total duty of 100V AC
is applied) 1.8A
(when total duty of 200V AC
is applied)
Output Holding Time 20 [msec] (Condition; ambient temp. 25
°C, rated input and
output)
Protection Circuit Over current protection, over voltage protection,
over temperature protection, over load protection
Parallel Operation Applicable
Operation Ambient Temp. 0 to 50
°C (with derating *1 )
Operation Ambient
Humidity
30 to 85%RH (non-condensing)
Cooling Method Natural air-cooling
Voltage Durability Output – input … 2000V AC 1min.
Input – housing …2000V AC 1min.
Insulation Strength Output – housing … 100M
W min. at 500V DC
Circuit System
Line-commutated flyback converter
Mass Approx. 0.9kg
*1 Derating: it is a method to use a device with a load lower than the rated value for the purpose to
decrease a risk of malfunction.
