SS Actuator
The name of the actuator parts are indicated below. The left and right sides are indicated by looking at the actuator
from the motor end with the actuator set down horizontally. Front end means the side opposite the motor end.
4. Name of the Parts
Right Side
Left Side
Motor Housing
Encoder Cover
Slider
Front Cover
Cable
Base
Reference Side
Motor Side
Reversed Motor Side
Side Cover
Upper Side
Lower Side
