Harrington Hoists and Cranes TCR Large Cap - (10-25 Ton) User Manual
Page 53
9 of 10
Figure
Number
Name Part
Number
Parts
Per
Hoist
173
WASHER M20
9012519
1
174
LIMIT LEVER THRUST PLATE
TCR426305W60
1
175 LIMIT
LEVER
TCR426305R61
1
176 DU
BUSHING
TCR130220025
1
177
HEX. SOCKET HEAD CAP SCREW
M10X15
9091292 1
178 CONTROL
LEVER
TCR426305L70
1
179 LOAD
CHAIN
LCTCR25000
FT
180 HOOK
CP
TCR426305S2B
2
180B
HOOK
SAFETY
CLAW
TCR420745P10
1
180C
HOOK
SPRING
TCR130802060
1
180D
HEX. SOCKET HEAD CAP SCREW
M8X45
9091277 1
180E
U NUT M8
9098506
1
181
CHAIN END PIN
TCR426305X81
1
182 WASHER
M24 9012521
3
183 WASHER
M20 9012519
1
184
U NUT M-20
9098520
1
185
GEAR COVER PACKING
TCR136102100
1
186
INTERNAL GEAR PACKING (N)
TCR136102139
1
190
FREE CHAIN WHEEL
TCR426305U20
1
191 YOKE
TCR426305Y60
2
192 BEARING
TCR130125220
2
193 OIL
SEAL
TCR131203150
2
194 THRUST
BEARING
TCR130121220
1
195 HOOK
THRUST
RING
TCR426305X90
1
196
HEX. SOCKET HEAD CAP SCREW
M24X90
90912146 2
197
SPRING WASHER M24 NARROW
9012719
4
198
HEX. NUT M24
9093445
2
201 LIMIT
ROLLER
TCR426305F20
1
202 LIMIT
SPACER
TCR426305F30
1
203 HEX.
BOLT
M12X50 9093374
1
204
PLAIN WASHER M12
9012515
1
205
HEX. NUT M12
9093433
1
206
SPRING WASHER M12
9012713
1
208
LIMIT LEVER (D)
TCR426305AC0
1
210
DOMED CAP NUT M10
9158705
1
220
S TYPE WIRE
TCR130802081
2
221R
THROTTLE VALVE CHANGE CORD -
RED
9013102 6
221W
THROTTLE VALVE CHANGE CORD -
WHITE
9013101 6
222 GRIP
(W)
AH136602625
1
223 GRIP
(R)
AH136602626
1
224 HANDLE
AH136602627
1
225
HEX. SOCKET HEAD CAP PLUG
TCR134901002
1
Figure
Number
Name Part
Number
Parts
Per
Hoist
226
HEX. SOCKET HEAD CAP PLUG
TCR420875BJ0
2
300 CHAMBER
CAP
TCR426307AL0
1
301
HEX.SOCKET HEAD CAP SCREW
M6X14
9091248 4
302 O
RING
TCR131103063
1
303 O
RING
MCR131103051
1
304 O
RING
TCR131103005
5
305 VALVE
BOX
TCR426307AM0
1
306 LIMIT
SPOOL
TCR426307AN0
1
307
LIMIT SPOOL BUSHING
TCR426307AP0
1
308 BOX
COVER
TCR426307AQ0
1
309 LIMIT
RETAINER
TCR426307AR0
1
310 ADJUST
COVER
TCR426307AS0
1
311 SPRING
SEAT
TCR426307Z50
1
312 SPRING
13X64X2
TCR130802276
1
313 LIMIT
GASKET
TCR136102170
1
314
HEX. SOCKET HEAD CAP SCREW
M5X40
9091233 4
315
HEX. SOCKET HEAD CAP SCREW
M5X14
9091227 8
316
HEX. SOCKET SET SCREW M6X25 TCR132306025
1
317
HEX. NUT M6
9043904
1
318 O-RING
TCR131103022
6
319
PARALLEL PIN 4X10
TCR130406005
3
320 RETAINING
RING 9047232
1
TCR25000
