Harrington Hoists and Cranes TCR Large Cap - (10-25 Ton) - Manual (Page 51)

7 of 10
Figure
Number
Name Part Number
Parts
Per
Hoist
1A METAL BUSHING TCR426305J90 1
1B DU BUSHING TCR130212012 1
1C O RING TCR131101012 1
2 O RING TCR131103035 1
3
HEX.SOCKET HEAD CAP SCREW
M5X12
9091226 4
4 VALVE BODY TCR426301A50 1
5 O RING TCR131151015 1
6 VALVE BUSHING TCR426301A60 1
7 THROTTLE VALVE TCR426301A70 1
9 VALVE SHAFT LEVER TCR426301J80 1
10 VALVE BODY PACKING TCR136102097 1
11
HEX.SOCKET HEAD CAP SCREW
M8X25
9091273 4
12 THROTTLE VALVE SPRING (S) TCR130802270 2
13 SPRING GUIDE (S) TCR426301G20 2
14 RETAINER CLIP TCR130307011 2
15 SPRING THRUST PLATE TCR426301R80 2
16 PISTON TCR426301F80 2
17 O RING TCR131151028 2
18 VALVE CAP TCR426301B30 2
19 O RING TCR131103033 2
20 O RING TCR131151006 2
21
HEX.SOCKET HEAD CAP SCREW
M6X20
9091250 8
22 CAP COVER TCR426301C80 2
23 O RING TCR131103026 2
24 THROTTLE VALVE SPRING (L) TCR130802271 2
25 SPRING SEAT TCR426301B50 2
26 SPRING SEAT SHAFT TCR426301B60 2
27 WASHER MCR136102095 2
28 HEX. NUT M6 9158703 2
29
HEX.SOCKET HEAD CAP SCREW
M5X35
9091232 8
30 ELEMENT HOLDER TCR426221G50 2
31 ELEMENT MCR136302010 2
32 PACKING TCR136102094 4
33 JOINT (STRAIGHT) TCR135108103 2
34 JOINT (ELBOW) TCR135108102 1
35
HEX.SOCKET HEAD CAP SCREW
M5X10
9091225 1
40 LIMIT VALVE SHAFT TCR426305T70 1
41 FLAT WASHER M12 9012515 1
42 RETAINING RING 9047112 1
43 HEX. NUT M8 9093424 1
44 LIMIT VALVE SHAFT WASHER TCR426305V30 1
Figure
Number
Name Part Number
Parts
Per
Hoist
45 VALVE SHAFT THRUST PLATE TCR426305G80 1
60 PENDANT VALVE CP AH420215VBC 1
60A THROTTLE VALVE AH420215VB0 2
60B PUSH ROD AH420215VC0 2
60C O-RING AH131118012 2
60D O-RING AH131117013 2
60E PENDANT VALVE BODY CP AH420215VRB 1
60EA PENDANT VALVE BODY AH420215VR0 1
60EB BUSHING AH420214VF0 2
60F O-RING AH131103016 2
060G SPRING PIN 4.5X32 9148160 2
60H PENDANT VALVE LEVER AH420210VH0 2
60J VALVE SPRING AH130802030 2
60K PENDANT VALVE CAP AH420214V10 2
60L O-RING TCR131103022 2
60M RETAINING RING AH130303004 2
62 JOINT TCR135108103 3
63 HINGE SCREW M6X30 9044403 1
64 HEX. NUT M6 9093420 1
65 PENDANT HOSE CP 60850 1
65A HOSE TCR137225020 FT
65B TUBE BLACK 8X6X2M TCR137208020 FT
65C TUBE RED 8X6X2M TCR137209020 FT
65D TUBE WHITE 8X6X2M TCR137210020 FT
65E STRAIN RELIEF ES625003 FT
65F S TYPE WIRE TCR130802081 1
66 PENDANT HOSE CP 60851 1
66B HOSE 9013141 3@FT
66C TUBE FITTING AH137291310 3
66E JOINT (ELBOW) 9013152 1
66D JOINT (STRAIGHT) 9013151 2
65E STRAIN RELIEF ES625003 FT
65F S TYPE WIRE TCR130802081 1
70 FRONT PLATE TCR426301K70 1
71 BEARING 9000507 2
72 ROTOR TCR426301K40 1
73 RETAINING RING 9047120 1
74 RETAINING RING 9047135 1
75 BRAKE WHEEL KEY TCR130408110 1
76 VANE TCR137102012 8
77 CYLINDER TCR426301K50 1
78 REAR PLATE TCR426301K20 1
79 CYLINDER KNOCK TCR130402008 1
80 CASE TCR426307K80 1
TCR25000C2/P2
