Harrington Hoists and Cranes TCR Large Cap - (10-25 Ton) - Manual (Page 52)

8 of 10
Figure
Number
Name Part Number
Parts
Per
Hoist
81 MOTOR COVER TCR426307N30 1
82 O RING TCR131103063 2
83 O RING TCR131103064 1
84 BRAKE VALVE TCR426301W30 2
85 O RING TCR131103007 2
86 BRAKE VALVE SPRING TCR130802272 2
87 BRAKE SHIFTER (M) TCR426301W80 1
88 BEARING TCR130116011 2
89 BRAKE DISC TCR426301P30 1
90 SHIFTER SPRING TCR130802273 1
91 SHIFTER SPRING SEAT TCR426301W70 1
92 BRAKE SHIFTER (S) TCR426301W90 1
93 BRAKE PISTON TCR426301Q70 1
94 O RING TCR131101077 1
95 BRAKE SPRING (S) TCR130802274 1
96 BRAKE SPRING (L) TCR130802275 1
97 BRAKE SPRING SEAT TCR426301B70 1
98 BRAKE CASE TCR426307P20 1
99 HEX.SOCKET SET SCREW M10X35 TCR132310035 1
100 HEX.NUT M10 TCR426301Q90 1
101
HEX.SOCKET HEAD CAP SCREW
M10X85
90912140 4
102 SILENCER TCR137402046 1
103 EXHAUST COVER TCR426301Q60 1
105
HEX.SOCKET HEAD CAP SCREW
M6X14
9091248 4
106 EXHAUST COVER SHAFT TCR426301U90 1
107 O RING TCR131103004 2
108 O RING TCR131101004 2
110 COUPLING TCR426305L20 1
111 PINION TCR426305L30 1
112 FIRST IDLE GEAR TCR426305L80 3
113 NEEDLE BEARING TCR130131220 3
114 FIRST FRAME TCR426305M10 1
115 BEARING TCR130116011 1
116 FIRST IDLE GEAR SHAFT TCR426305M20 3
117 FIRST INTERNAL GEAR TCR426305L90 1
118 CONED DISK SPRING TCR426305L40 1
119 SECOND IDLE GEAR TCR426301M40 3
120 NEEDLE BEARING TCR130132520 3
121 SECOND FRAME TCR426301M70 1
122 SECOND IDLE GEAR SHAFT TCR426301M50 3
123 SECOND INTERNAL GEAR TCR426301M60 1
124 BEARING TCR130116024 2
125 INTERNAL GEAR SPACER TCR426301K60 1
Figure
Number
Name Part Number
Parts
Per
Hoist
126 THIRD IDLE GEAR TCR426301N40 3
127 NEEDLE BEARING TCR130132530 3
128 THIRD FRAME TCR426305N71 1
129 PINION SPACER TCR426305AD0 1
131 THIRD IDLE GEAR SHAFT TCR426301N50 3
132 THIRD INTERNAL GEAR TCR426301N60 1
133 THIRD INTERNAL GEAR SPACER TCR426305N91 1
134 LAST IDLE GEAR TCR426305V41 3
135 NEEDLE BEARING TCR130132130 6
137 LAST FRAME TCR426305V62 1
138 BEARING 9000107 1
139 BEARING 9000502 1
140 PARALLEL PIN 4X10 TCR130406005 3
141 LAST IDLE GEAR SHAFT TCR426305V71 3
142 LAST INTERNAL GEAR TCR426305V81 1
143 BEARING 9001212 2
144 BEARING 9000924 1
145 KNOCK PIN TCR426305L61 6
146 GEAR CASE TCR426305N80 1
147 SPRING PIN 8X20 91481117 3
148 INTERNAL GEAR KEY TCR130408111 1
149 BRAND NAME PLATE 80103 1
150 RIVET NO.0X3.2 MCR133001110 8
151 GEAR COVER TCR426305N20 1
152 BEARING 9000202 1
153
HEX. SOCKET HEAD CAP SCREW
M10X25
9091294 6
154 NAME PLATE 25TON 80105 1
155
HEX. SOCKET HEAD CAP SCREW
M16X70
90912143 6
156
HEX. SOCKET HEAD CAP SCREW
M16X35
90912142 5
160 LOAD SHEAVE TCR426305R22 1
161 SIDE PLATE (M) TCR426305D50 1
162 SIDE PLATE (G) TCR426305D61 1
163 BEARING 6220DDU 90010xx 1
164 CHAIN SEPARATOR TCR426305R40 1
165 SPRING PIN 12X45 91481168 2
166
HEX. SOCKET HEAD CAP SCREW
M24X90
90912146 2
167 SPRING WASHER M24 NARROW 9012719 4
168 HEX. NUT M24 9093445 2
169 O-RING TCR131103195 1
170 CHAIN SET SPINDLE TCR426305X60 1
171 HEX. NUT M24 9043911 1
172 SPRING WASHER M24 9012719 1
TCR25000
