Harrington Hoists and Cranes TCR Large Cap - (10-25 Ton) - Manual (Page 47)

3 of 10
Figure
Number Name Part Number
Parts
Per
Hoist
1A METAL BUSHING TCR426305J90 1
1B DU BUSHING TCR130212012 1
1C O-RING TCR131101012 1
2 O-RING TCR131103035 1
3
HEX.SOCKET HEAD CAP SCREW
M5X12
9091226 4
4 VALVE BODY TCR426301A50 1
5 O-RING TCR131151015 1
6 VALVE BUSHING TCR426301A60 1
7 THROTTLE VALVE TCR426301A70 1
9 VALVE SHAFT LEVER TCR426301J80 1
10 VALVE BODY PACKING TCR136102097 1
11
HEX.SOCKET HEAD CAP SCREW
M8X25
9091273 4
12 THROTTLE VALVE SPRING TCR130802270 2
13 SPRING GUIDE TCR426301G20 2
14 RETAINER CLIP TCR130307011 2
15 SPRING THRUST PLATE TCR426301R80 2
16 PISTON TCR426301F80 2
17 O-RING TCR131151028 2
18 VALVE CAP TCR426301B30 2
19 O-RING TCR131103033 2
20 O-RING TCR131151006 2
21
HEX.SOCKET HEAD CAP SCREW
M6X20
9091250 8
22 CAP COVER TCR426301C80 2
23 O-RING TCR131103026 2
24 THROTTLE VALVE SPRING (L) TCR130802271 2
25 SPRING SEAT TCR426301B50 2
26 SPRING SEAT SHAFT TCR426301B60 2
27 WASHER MCR136102095 2
28 HEX. NUT M6 9158703 2
29
HEX.SOCKET HEAD CAP SCREW
M5X35
9091232 8
30 ELEMENT HOLDER TCR426221G50 2
31 ELEMENT MCR136302010 2
32 PACKING TCR136102094 4
34 JOINT (ELBOW) TCR135108102 1
34A JOINT (STRAIGHT) TCR135108103 2
35
HEX.SOCKET HEAD CAP SCREW
M5X10
9091225 1
40 LIMIT VALVE SHAFT TCR426305T70 1
41 FLAT WASHER M12 9012515 1
Figure
Number Name Part Number
Parts
Per
Hoist
42 RETAINING RING 9047112 1
43 HEX NUT M8 9093424 1
44 LIMIT VALVE SHAFT WASHER TCR426305V30 1
45 VALVE SHAFT THRUST PLATE TCR426305G80 1
60 PENDANT VALVE CP AH420215VBC 1
60A THROTTLE VALVE AH420215VB0 2
60B PUSH ROD AH420215VC0 2
60C O-RING AH131118012 2
60D O-RING AH131117013 2
60E PENDANT VALVE BODY CP AH420215VRB 1
60EA PENDANT VALVE BODY AH420215VR0 1
60EB BUSHING AH420214VF0 2
60F O-RING AH131103016 2
60G SPRING PIN 4.5X32 9148160 2
60H PENDANT VALVE LEVER AH420210VH0 2
60J VALVE SPRING AH130802030 2
60K PENDANT VALVE CAP AH420214V10 2
60L O-RING TCR131103022 2
60M RETAINING RING AH130303004 2
62 JOINT TCR135108103 3
63 HINGE SCREW M6X30 9044403 1
64 HEX. NUT M6 9093420 1
65 PENDANT HOSE CP 60850 1
65A HOSE TCR137225020 1
65B TUBE BLACK TCR137208020 FT
65C TUBE RED TCR137209020 FT
65D TUBE WHITE TCR137210020 FT
65E STRAIN RELIEF ES625003 FT
65F S TYPE WIRE TCR130802081 1
66 PENDANT HOSE CP 60851 1
66B HOSE 9013141 3@FT
66C TUBE FITTING AH137291310 3
66D STRAIGHT CONNECTOR 9013151 2
66E ELBOW CONNECTOR 9013152 1
65E STRAIN RELIEF ES625003 FT
65F S TYPE WIRE TCR130802081 1
70 FRONT PLATE TCR426301K70 1
71 BEARING 6007ZZ 9000507 2
72 ROTOR TCR426301K40 1
73 RETAINING RING 9047120 1
74 RETAINING RING 9047135 1
75 BRAKE WHEEL KEY TCR130408110 1
TCR10000C2/P2
