Harrington Hoists and Cranes TCR Large Cap - (10-25 Ton) User Manual
Page 49
5 of 10
Figure
Number
Name Part
Number
Parts
Per
Hoist
165 HOOK
CP
TCR426303S2B
2
165B
HOOK
SAFETY
CLAW
TCR420890P10
1
165C
HOOK
SPRING
TCR130802046
1
165D SPRING PIN 3X24
TCR130603024
1
166
HOOK END PIECE
TCR426303AH0
1
167 HANGER
PIN
TCR426303AG0
2
168 WASHER
TCR426303R50
2
169
U NUT M16
9098516
2
170
SPRING WASHER M16
9012715
2
171
HEX. SOCKET HEAD CAP SCREW
M12X60
90912120 2
172
CHAIN SET PLATE
TCR426303X40
1
173
CHAIN SET PLATE SHAFT
TCR426301X50
2
174
SPLIT PIN 5X35
9009445
3
175
HEX. SOCKET HEAD CAP SCREW
M10X130
90912141 1
176
U NUT M10
9098508
1
177
PLAIN WASHER M10
9012514
1
178
CHAIN SET SPINDLE
TCR426303X60
1
179 CHAIN
END
CONNECTOR
TCR426301X70
1
180
CHAIN END PIN
TCR426301X80
1
181
SPLIT PIN 4X32
9009436
1
182 LOAD
CHAIN
LCTCR10000
FT
190
FREE CHAIN WHEEL
TCR426303U20
1
191
FREE WHEEL PIN
TCR426303AJ0
1
192 YOKE
TCR426303Y60
1
193
HOOK SLIDE RING
TCR426303X90
1
194 NEEDLE
BEARING
TCR130134020
4
195 SEAL
TCR131212040
2
196 THRUST
BEARING
TCR130121114
1
197
HEX. SOCKET HEAD CAP SCREW
M16X75
90912144 2
198
SPRING WASHER M16
9012715
2
199
HEX. NUT M16
9093439
2
210
DOMED CAP NUT M10
9158705
1
220
S TYPE WIRE
TCR130802081
2
221R RED
CORD
9013102 FT
221W WHITE
CORD
9013101 FT
222 GRIP
(W)
AH136602625
1
223 GRIP
(R)
AH136602626
1
224 HANDLE
AH136602627
1
Figure
Number
Name Part
Number
Parts
Per
Hoist
225
HEX. SOCKET HEAD CAP PLUG
TCR134901002
1
226
HEX. SOCKET HEAD CAP PLUG
TCR420875BJ0
2
300 CHAMBER
CAP
TCR426307AL0
1
301
HEX.SOCKET HEAD CAP SCREW
M6X14
9091248 4
302 O
RING
TCR131103063
1
303 O
RING
MCR131103051
1
304 O
RING
TCR131103005
5
305 VALVE
BOX
TCR426307AM0
1
306 LIMIT
SPOOL
TCR426307AN0
1
307
LIMIT SPOOL BUSHING
TCR426307AP0
1
308 BOX
COVER
TCR426307AQ0
1
309 LIMIT
RETAINER
TCR426307AR0
1
310 ADJUST
COVER
TCR426307AS0
1
311 SPRING
SEAT
TCR426307Z50
1
312 SPRING
13X64X2
TCR130802276
1
313 LIMIT
GASKET
TCR136102170
1
314
HEX. SOCKET HEAD CAP SCREW
M5X40
9091233 4
315
HEX. SOCKET HEAD CAP SCREW
M5X14
9091227 8
316
HEX. SOCKET SET SCREW M6X25 TCR132306025
1
317
HEX. NUT M6
9043904
1
318 O-RING
TCR131103022
6
319
PARALLEL PIN 4X10
TCR130406005
3
320 RETAINING
RING
9047232 1
TCR10000C2/P2
