Harrington Hoists and Cranes TCR Large Cap - (10-25 Ton) - Manual (Page 48)

4 of 10
Figure
Number Name Part Number
Parts
Per
Hoist
76 VANE TCR137102012 8
77 CYLINDER TCR426301K50 1
78 REAR PLATE TCR426301K20 1
79 CYLINDER KNOCK TCR130402008 1
80 CASE TCR426307K80 1
81 MOTOR COVER TCR426307N30 1
82 O RING TCR131103063 1
83 O RING TCR131103064 1
84 BRAKE VALVE TCR426301W30 2
85 O RING TCR131103007 2
86 BRAKE VALVE SPRING TCR130802272 2
87 BRAKE SHIFTER (M) TCR426301W80 1
88 BEARING TCR130116011 2
89 BRAKE DISC TCR426301P30 1
90 SHIFTER SPRING TCR130802273 1
91 SHIFTER SPRING SEAT TCR426301W70 1
92 BRAKE SHIFTER TCR426301W90 1
93 BRAKE PISTON TCR426301Q70 1
94 O RING TCR131101077 1
95 BRAKE SPRING (S) TCR130802274 1
96 BRAKE SPRING (L) TCR130802275 1
97 BRAKE SPRING SEAT TCR426301B70 1
98 BRAKE CASE TCR426307P20 1
99 HEX.SOCKET SET SCREW M10X35 TCR132310035 1
100 HEX.NUT M10 TCR426301Q90 1
101
HEX.SOCKET HEAD CAP SCREW
M10X85
90912140 4
102 SILENCER TCR137402046 1
103 EXHAUST COVER TCR426301Q60 1
105
HEX.SOCKET HEAD CAP SCREW
M6X14
9091248 4
106 EXHAUST COVER SHAFT TCR426301U90 1
107 O RING TCR131103004 2
108 O RING TCR131101004 2
110 COUPLING TCR426301L20 1
111 PINION TCR426301L30 1
112 FIRST IDLE GEAR TCR426301L80 3
113 NEEDLE BEARING TCR130131220 3
114 FIRST FRAME TCR426301M10 1
115 BEARING 9000110 1
116 FIRST IDLE GEAR SHAFT TCR426301M20 3
117 FIRST INTERNAL GEAR TCR426301L90 1
Figure
Number Name Part Number
Parts
Per
Hoist
118 CONED DISK SPRING TCR426301L50 1
119 SECOND IDLE GEAR TCR426301M40 3
120 NEEDLE BEARING TCR130132520 3
121 SECOND FRAME TCR426301M70 1
122 SECOND IDLE GEAR SHAFT TCR426301M50 3
123 SECOND INTERNAL GEAR TCR426301M60 1
124 BEARING TCR130116024 2
125 INTERNAL GEAR SPACER TCR426301K60 1
126 THIRD IDLE GEAR TCR426301N40 3
127 NEEDLE BEARING TCR130132530 3
128 THIRD FRAME TCR426301N70 1
129 BEARING 9000502 1
130 RETAINING RING 9047232 1
131 THIRD IDLE GEAR SHAFT TCR426301N50 3
132 THIRD INTERNAL GEAR TCR426301N60 1
133 GEAR CASE TCR426301N80 1
134 SPRING PIN 8X20 91481117 6
135 BRAND NAME PLATE - H'TON 80103 1
136 RIVET NO.0X3.2 MCR133001110 8
137 GEAR COVER TCR426301N20 1
138 BEARING 9000202 1
139 O RING TCR131117166 1
140
HEX. SOCKET HEAD CAP SCREW
M10X25
9091294 6
141 NAME PLATE 10 TON 80104 1
145 LOAD SHEAVE TCR426301R20 1
146 CHAIN GUIDE TCR426301R30 1
147 BEARING 9000915 1
148 O RING TCR131103063 1
149 CHAIN GUIDE COVER TCR426301U80 1
150 BEARING 9001015 1
151 KNOCK PIN TCR426301L60 3
152 CHAIN SEPARATOR TCR426303R40 1
153 CHAIN SEPARATOR PIN TCR426301U40 1
154 MIDDLE PLATE (G) TCR426303C60 1
155 MIDDLE PLATE (M) TCR426303C70 1
156
HEX SOCKET HEAD CAP SCREW
M16X170
90912145 5
157 SPRING WASHER M16 9012715 5
158 HEX. NUT M16 9093439 5
159 LIMIT LEVER U TCR426303R60 1
160 LIMIT LEVER D TCR426303AC0 1
164 CONTROL LEVER TCR426303L70 1
TCR10000C2/P2
