46
9.2 Additional 2 through 5 Ton Parts
Figure 9-3 Additional 2 through 5 Ton Parts
Fig.
No.
Name
Parts /
Hoist
2 Ton 3 Ton 5 Ton
44 Suspender 1 50622 50679
46 Chain Pin 1 CF041020 M3041030
47 Slotted Nut for Fig. 46 1 M2049010
48 Split Pin for Fig. 46 1 9009411
49 Bottom Hook Complete Set 1 CF021A020 M3021A030
50 Bottom Yoke 2 CF031020 M3031030
51 Bolt 2 9091274 9091296
52 U-Nut 2 9098506 9098508
53 Shaft 1 CF053020 CF053030
54 Spring Pin 1 CF083020
55 Idle Sheave 1 CF051020 CF051030
56 Bottom Hook Assembly 1 CF021020 M3021030
57 Latch Assembly 1 CF071020 CF071030
58 Suspender Assembly 1 50727
59 Suspender 1 50725
60 Idle Sheave Bracket L.H. 1 5072601
61 Idle Sheave 1 CF051030
62 Shaft 1 CF053050
63 Spring Pin 1 CF083020
64 Bolt 2 9093153
65 Lock Nut 2 9098511
66 Idle Sheave Bracket R.H. 1 5072602
68 Bottom Hook Complete Set 1 CF021A050
69 Bottom Yoke Assembly 1 CF031050
70 Idle Sheave 1 CF051030
71 Shaft 1 CF053050
72 Spring Pin 1 CF083020
73 Socket Bolt 2 9091296
74 U-Nut 2 9098508
75 Bottom Hook Assembly 1 M3021050
76 Latch Assembly 1 CF071050
