Harrington Hoists and Cranes (G)NTH Trolley - Manual (Page 45)

45
9.1 1 to 5 Ton Parts
Fig.
No.
Name
Parts /
Hoist
1Ton 2 Ton 3 Ton 5 Ton
1 Suspender 1 50604 50622 50679 50725
3 Top Pin 1 CF163010 CF163015
4 Bottom Hook Complete Set 1 M3021A010
6 Latch Assembly 1 CF071010
7 Chain Pin 1 M3041010
8 Slotted Nut 1 M2049010
9 Split Pin 1 9009411
10 Body A 1 CF101010 CF101015
11 Body B 1 CF102010 CF102015
12
Name Plate
- Blank without rivets 1 CF800010B CF800020B CF800030B CF800050B
with rivets 1 CF4800010 CF4800020 CF4800030 CF4800050
13 Frame 1 CF105010 CF105015
14 Pinion 1
CF111010** CF111015** CF111050**
CF4111010* CF4111015* CF4111050*
15 Ball Bearing A 1 9000103
16 Ball Bearing B 1 9000201 9000202 9000300
17 Ball Bearing C 1 9000105 9000106
17A Ball Bearing D 1 9000105 9000106
18 Load Sheave 1 CF116010 CF116015 CF116A050
19 Load Gear 1 CF114010 CF114015 CF116A050
20 Chain Guide 1 CF178010 CF178015
21 Stripper 1 CF162010 CF162015
22 Socket Bolt for Body 2 9091284 9091285
22A Socket Bolt for Body 2 9091282 9091283
23 U-Nut for Body 4 9098506
24 Pawl Pin 1 CF156005
25 U-Nut for Fig. 24 1 9098506
26 Pawl Spring 1 CF158005
27 Pawl 1 CF155005
28 Snap Ring for Fig. 24 1 9047108
29 Friction Disc 1
CF153010**
M3153020*
30 Ratchet Disc 1
CF152010**
CF4152010*
31 Bushing for Ratchet Disc 1 M3154020*
32 Friction Plate
2 M3151020*
1 CF151010**
32-A Friction Plate 1 CF150010**
33 Hand Wheel 1
CF115010** CF115015**
CF4115010* CF4115015*
34 Wheel Stopper 1 CF159010
35 Wheel Stopper Pin 1 M2167005
36 Split Pin for Fig. 35 1 9009401
37 Wheel Cover 1 CF171010 CF171015
38 Screw for Fig. 37 3 CF187005
39 Spring Washer for Fig. 37 3 9012709
40 Tail Pin 1 CF164010 CF164015
41 Socket Bolt for Fig. 40 1 CF181010
42 Load Chain ft. LCCF010 LCCF015
43 Hand Chain ft. HCCF005
77 Warning Tag 1 WTAG9
78 Chain Stopper Link 1 L4045030
*CF4 model only
**Parts discontinued
