Harrington Hoists and Cranes TNER Theater Hoist User Manual
Page 49
Fig No
Part Name
Parts Per
Hoist
005L
010L
020L
1
Limit Switch Assembly
1
ER1BS1551
2
Socket Bolt
3
9091247
3
Spring Washer
3
9012709
4
Plate Assembly
1
SA1DHM05L5A2
SA1DHM10L5A2
5 Transformer
3
TRF62M611
6 Machine Screw
2
MS555010
7 Terminal Plate
1
ECP1309AD
8 Mach. Screw w/ Spring Washer
2
J1AW24001010
9 E-Stop Contactor
1
MGC14306C
10 Mach. Screw w/Spring Washer
2
MS556010
11 Electromagnetic Contactor
1
MGC23406C
12 Machine Screw
2
J1AP24001212
13 Plate Screw
2 (3)
ER1BS9445
14 Fuse
1
ECP91FZ06
15 Fuse Holder
1
ECP92FZAA
16 Mach. Screw w /Spring Washer
1
E2D667125
17 Mach. Screw w /Spring Washer
2
MS555010
18 Lead Wire Assembly
1
SA1DHM05L9A2
SA1CHM10L9A2
*Quantities in “()” are for 010L and 020L hoists.
