1 housing and motor parts, 1 h ous ing a nd m o tor p a rt s – Harrington Hoists and Cranes TNER Theater Hoist User Manual
Page 40
Figure
No.
Part Name
Parts Per
Hoist
005L
010L
020L
24
Motor Frame with Stator
208-230/460V-3-60
1
SA1DHM05L5A1
SA1DHM010L5A1
25
Socket Bolt
4
90912138
9091275
26
Set Pin S
2
ES120003
ES120010S
27
Packing M
1
ER1BS9118
ER1CS9118
28
Body B
1
SA1BL9101
SA1CL9101
30
Oil Plug
2
E3S111003
31
Plug Packing
2
E3S112003
32
Set Pin S
2
ES1200035
33
Packing G
1
ER1BS9116
ER1CS9116
35
Gear Case F
1
SA1BL9103
SA1CL9103
36
Socket Bolt
4
9091259
37
Toothed Lock Washer
4
9679709
38
Name Plate SP
1
SA1DHM05I9B6
SA1DHM10I9B6
SA1DHM20I9B6
39
Oil Plug B
2
SA1BS9135
40
Eyebolt Packing
1
ES127005S
42
Bending Washer
1
SA1BS9983
43
Spring Pin
1
E3S129005S
44
Handle
2
SA1CL9963
45
Socket Bolt
4
9091250
48
Packing C
1
ER1BS9117
ER1CS9117
50
Socket Bolt
4
9091238
9091239
51
Toothed Lock Washer
4
9679708
52
Name Plate B
1
SA1CHM05L9A3
SA1CHM10L9A3
53
Warning Sticker E
(Disconnect Power)
1
ER2CS9936
55
Grease Warning Label
1
80470
56
Voltage Changer Warning
Label
1
80485
57
TNER Logo Label
1
80483
58
BGV-D8 Logo Label
1
80486
59
CE Mark Label
1
80487
60
Controller Cover
1
SA1BL9104
SA1CL9104
61
Wiring Diagram
1
EWE4A00H1
40
9
.1
H
ous
ing a
nd M
o
tor
P
a
rt
s
