1 housing and motor parts, 1 h ous ing a nd m o tor p a rt s – Harrington Hoists and Cranes TNER Theater Hoist User Manual
Page 39
Figure
No.
Part Name
Parts Per
Hoist
005L
010L
020L
1
Frame Cover
1
SA1BL9207
SA1CL9207
2
Socket Bolt
4
9091233
3
Toothed Lock Washer
4
9679708
8
Nut
1
ES217005S
9
Lock Washer
1
ES218005S
10
Spacer
1
SA1BL9313
ES216S005
11
Motor Cover Assembly
1
ER1BS2106
ER1CS2106
12
Socket Bolt
4
9091251
9091273
13
Spring Washer
4
9012709
9012711
14
Collar M
1
ES192005S
15
Coned Disc Spring M
4
E3S191005S
16
Brake Drum Assembly
1
ER1BS5212
ER1CS5212
17
Brake Spring
1
ES214003
ES214005S
18
Thrust Collar
1
ES506003
ES506005S
19
Thrust Disc
2
ES505003
ES505005S
20
Pull Rotor
1
ES503003
ES503005S
21
Coned Disc Spring
1
ES504003
ES504005S
22
Motor Shaft with Rotor
1
SA1BL5502
SA1CL5502
39
9
.1
H
ous
ing a
nd M
o
tor
P
a
rt
s
