Harrington Hoists and Cranes TNER Theater Hoist - Manual (Page 45)

Figure
No.
Part Name
Parts Per
Hoist
005L 010L 020L
2 Chain Clip 1 SA1BS9422
3 Suspender D 1 SA1CR9030
5 Yoke Bolt 1 SA1CR9032
6 Slotted Nut 1 ES088020L
7 Split Pin 1 9009436
8 Body Hook Complete Assembly 1 SA1BS1001 SA1CS1001 SA1CR1001
9 Hook Latch Assembly 1 CF071010 CF071015 CF071030
10 Chain Pin 1 M2041010
11 Slotted Nut 1 M2049010
12 Split Pin 1 9009412
13 Connection Shaft 1 ER1BS9121 ER1CS9121
14 O Ring 2 9013306 9013309
15 Plate A 1 ER1BS9123
16 Machine Screw w/ Spring Washer 2 J1AP25001212
18 Fixing Shaft Assembly 1 ER1BS1122 ER1CS1122
19 O Ring 2 9013305
20 Shaft Plug 1 ER1BS9128 ER1CS9128
22 Machine Screw 1 9798543
26 Chain Hook Complete Assembly 1 SA1BL1011 SA1CL1011 SA1CR1011
28 Hook Latch Assembly 1 ER1BS1002 ER1DS1002 ER1ES1002
29 Thrust Collar A 1 ES026003 ES026010L
30 Hook Stopper 2 ES027003 ES027010L
31 Thrust Bearing 1 ES022003 ES022010L
32 Bottom Shaft Assembly 1 ER2DR6023
33 Idle Sheave Assembly 1 27SH010S1103
34 Bottom Yoke Assembly 1 SA1CR2015
35 Bolt 2 90931215
36 Spring Washer 2 9012711
37 Nut 2 9093424
38 Name Plate C 1 M3805030
39 Ball Stopper Set 1 SA1CS9041 SA1CL9041
40
Load Chain (Nickel Plated DIN) 1 LCER005NP-DIN LCER010NP-DIN
Load Chain (Black)* 1 LCER005C LCER010C
41 Chain Coupling 1 P2HC0051121
42 Socket Bolt w/ Spring Washer 2 J1BG10602020 J1BG10602525
*The black load chain is optional. The hoist will not have CE Conformance with the black chain installed.
9.
3
H
o
o
k P
a
rt
s
45
