Options:
Option
Number
Option Name What it Does Switches Used to Select Options
Option #1 Audio Ramping Speeds
Immediate Ramping Speed DipSw. #6 = Off DipSw. #7 = Off
Fast Ramping Speed DipSw. #6 = On DipSw. #7 = Off
Medium Ramping Speed DipSw. #6 = Off DipSw. #7 = On
Slow Ramping Speed DipSw. #6 = On DipSw. #7 = On
Option #3
(Modes 1d and
1E only)
Audio Mute Levels (Fades
background SoundFiles(s) to
this level before starting fore-
ground SoundFiles)
Ramps to Muted DipSw. #6 = Off DipSw. #7 = Off
Ramps to -33dB DipSw. #6 = On DipSw. #7 = Off
Ramps to -18dB DipSw. #6 = Off DipSw. #7 = On
Ramps to -9dB DipSw. #6 = On DipSw. #7 = On
Option #2 Loop selected SoundFiles on sustained inputs DipSw. #6 = Off DipSw. #7 = Off
Option #6 SoundFiles do not Loop on sustained inputs (v1.16+ only) DipSw. #6 = On DipSw. #7 = Off or On
Option #7 Loop ALL selected SoundFiles on sustained inputs (v1.16+) DipSw. #6 = Off DipSw. #7 = On
Option #8 DipSw. #8 = Off: SoundFiles played sequentially DipSw. #8 = On: Selected SoundFiles played randomly
Option #9 DipSw. #9 = Off: Triggered SoundFiles steppable DipSw. #9 = On: Triggered SoundFiles Unsteppable
Option #10 DipSw. #10 = Off: Amplifier enabled only while playing DipSw. #10 = On: Amplifier always Enabled
Operating Modes:
The first five DipSwitches are used to set the mode
of operation for the Sd-25. The remaining five
DipSwitches set the ʻoptionsʼ. The ʻonʼ/ʼoffʼ after
each ʻmodeʼ shows which of the first five
DipSwitches need to be turned ʻonʼ or ʻoffʼ to select
that mode. As an example; to select ʻmode Bʼ, you
would turn ʻonʼ switches one, two and four. Switches
three and five would be turned ʻoffʼ.
Sometimes when the operating mode is switched,
you may need to cycle power to the Sd-25 to assure
it operates as expected.
If you need your SoundFiles(s) to just loop:
use mode 0.
DipSwitches one though five = off/off/off/off/off
If you need to trigger one or more Sound-
Files(s): use mode C.
DipSwitches one though five = off/off/on/on/off
Mode 0 / off/off/off/off/off
Loops with Mutes. Fade to -3dB on ʻbʼ
Mode 1 / on/off/off/off/off
Loops with Mutes. Fade to -6dB on ʻbʼ
Mode 2 / off/on/off/off/off
Loops with Mutes. Fade to -9dB on ʻbʼ
Mode 3 / on/on/off/off/off
Loops with Mutes. Fade to -12dB on ʻbʼ
Mode 4 / off/off/on/off/off
Loops with Mutes. Fade to -18dB on ʻbʼ
Mode 5 / on/off/on/off/off
Loops with Mutes. Fade to -24dB on ʻbʼ
Mode 6 / off/on/on/off/off
Loops with Mutes. Fade to -33dB on ʻbʼ
Mode 7 / on/on/on/off/off
Loops with Mutes. Fade to -48dB on ʻbʼ
Loop all the SoundFiles on the Sd-25, starting at
PowerUp. Input ʻaʼ will ramp the audio to a fully
muted level when activated. The ʻbʼ input ramps the
audio to a ʻhalf mutedʼ (lower) volume. The only dif-
ference among these eight modes is the ʻmutedʼ
volume level the ʻbʼ input selects. These modes will
support up to 32,767 SoundFiles.
Options:
Option #1: DipSwitches #6 and #7 are used to se-
