35
3. Make certain the cover lines up with the support runner of the
computer’s case (Figure 28). The video adapter board should be
firmly in place and not misaligned with the access port slot. If the
video adapter board appears “tweaked” you will need to carefully
realign the case back onto the computer.
4. Finish sliding the cover onto the computer until it lines up with
the rear of the computer (Figure 29).
Power Macintosh 7100 Installation
cover should align with support runner
Figure 28: Make certain cover aligns with support runner
Figure 29: Finish sliding cover onto computer
adapter board should be firmly in place
