11
Power Macintosh 6100 AV Installation
Disassemble AV Card from Bracket
1. Using a medium Phillips screwdriver, remove the screw that secures
the AV card to the bracket (Figure 5). Set the screw aside. Unplug
the AV card from the AV adapter.
Remove the Two Screws that Secure the Adapter
Using a medium Phillips screwdriver, remove the two screws that secure
the adapter to the bracket (Figure 6). Remove the adapter from the
bracket. Set the two screws and adapter aside.
Remove Level 2 Cache Card
If your computer contains a Level 2 cache card, remove it. If you are
uncertain about whether you have a Level 2 cache card, or where it might
be located, consult your computer’s documentation or see Chapter 10,
“Removing a Level 2 Cache Card.”
Figure 5: Remove screw that secures AV card to bracket
Figure 6: Remove screws that secure adapter to bracket
adapter
bracket
