Page 22: Upply
30
1
NOTE
J1 [ ] 115VAC INPUT (NOT USED)
[ ] 230VAC INPUT (USED, 05 JUMPER)
31
1
NOTE
J2,3 [ ] 115VAC INPUT (USED 05 JUMPER)
[ ] 230VAC INPUT (NOT USED)
X120-LPS-125 Power Supply
Item
Qty
Part Number
Description
I.D.
1
1
X120-1002B
PCB
2
1
CP-66
CARD EJECTOR
3
1
7101P4D9AQE
SWITCH, TOGGLE/PCB/SPDT
S1
4
1
312.100
FUSE, 0.1 AMP
F1
5
2
3529
FUSE HOLDER
6
1
RC07GF471J
RESISTOR, CF/470/.25/5
R6
7
2
RC07GF100J
RESISTOR, CF/10/.25/5
R4,5
8
1
7200-25
INDUCTOR
R2
9
1
RC42GF820J
RESISTOR, CF/82/2/5
R7
10
1
RC42GF273J
RESISTOR, CF/27K/2/5
R1
11
1
RN55C5112F
RESISTOR, MF/51.1K/.125/1
R3
12
1
101R501M05
CAPACITOR, RAD/MIC/100P/500
C3
13
1
105R500C20
CAPACITOR, RADIAL/CERAMIC/1M
C5
14
1
104A101C20
CAPACITOR, AXIAL/CERAMIC/.1M/100
C2
15
2
503R501C20
CAPACITOR, RADIAL/CER/0.5M/500
C1,7
16
1
685R350T10
CAPACITOR, RADIAL/TAN/6.8M/35
C6
17
1
157A250E28
CAPACITOR, AXIAL/ELE/150M/25
C4
18
2
NOT USED
COMPONENTS NOT USED
D2,3
19
2
1N4937
DIODE, REC/600/1
D4,5
20
2
1N4005
DIODE, REC/600/1
D6,7
21
1
1N963B
DIODE, ZENER/.4/12/10M
D1
22
1
MBR160
DIODE, SCHOTTKY
D9
23
2
IRFF420
FET, N/CHANNEL/500
Q1,2
24
2
0771786N
PAD, TRANSISTOR
Q1,2
25
2
22260R
HEATSINK
ON Q1,2
26
1
CD4047B
IC, BUF/MULTIVIB/LOW/PWR
U1
27
1
CD4041UBE
IC, BUF/TRUE/COMP/GT/QUAD
U2
28
1
LM7805CT
VOLTAGE REGULATOR 5V TO –220
REG1
29
1
HLMP-3300
LED, RED/HI/.198
LED1
30
1
RY-6WZ-K
RELAY
K1
31
1
X120B25-1
TRANSFORMER, DC/DC
T1
32
2
05JUMPERS
JUMPER, .5/.125/22AWG/PVC
J1,3
33
2
NOT USED
COMPONENTS NOT USED
J2,D8
34
1
6072B
HEATSINK
REG1
35
1
4-40 X 3/8
SCREW, PHIL/PAN/HD
REG1
36
1
#4
WASHER, SPRING LOCK SST
REG1
37
1
4-40 HEX
HEX NUT
REG1
