Ronan X120 - Manual (Page 16)

X120-GD-24 Ground Detector Module
Item Qty Part Number Description I.D.
1 1 X120-1003A PCB KEY 3-4
2 1 LM393N IC, COMP, LP, LO, DUAL U1
3 1 68WR1MEG POTENTIOMETER, CERAMIC 1M/20 R15
4 3 RC07GF103J RESISTOR, CF, 10K, .25, 5 R16,17,21
5 5 RC07GF105J RESISTOR, CF, 1M, .25, 5 R6,11,13,14,20
6 2 RC07GF115J RESISTOR, CF, 1.1M, .25, 5 R9,12
7 2 RC07GF156J RESISTOR, CF, 15M, .25, 5 R7,8
8 1 RC20GF472J RESISTOR, CF, 4.7K, .5, 5 R3
9 2 RC20GF512J RESISTOR, CF, 5.1K, .5, 5 R1,2
10 2 RC20GF513J RESISTOR, CF, 51K, .5, 5 R4,5
11 2 103A101C10 CAPACITOR, AXIAL, CERAMIC, 0.1M C1,2
12 3 1N4148 DIODE, SIGNAL, 75V, 400M CR1,2,R12
13 1 1N4005 DIODE, REC, 600, 1 CR4
14 2 RC07GF1RJ RESISTOR, CF, 1, .25, 5 CR5,R10
15 1 HLMP3001 LED, RED, STANDARD, .19 POWER
16 2 HLMP1300 LED, RED, STANDARD LED1,2
17 1 2N4249 TRANSISTOR, PNP, 60, 92 Q1
18 1 2N3568 Q2
19 1 T82S11D11424VD
C RELAY, GP, PCB, 24DC, DPDT K1
20 1 CP-66 CARD EJECTOR PCB
21 2 22 AWG WIRE, 22 GA BUSS R18,19
X120-GD-125 Ground Detector Module
Item Qty Part Number Description I.D.
1 1 X120-1003A PCB KEY 3-4
2 1 LM393N IC, COMP, LP, LO, DUAL U1
3 1 RC07GF472J RESISTOR, CF, 4.7K, .25, 5
NOTE: STAND A 4.7K OHM RESISTOR ON END &
CONNECT FROMSILKSCREEN SIDE R13 TO SILKSCREEN
SIDE R14.
4 3 RC07GF273J RESISTOR, CF, 27K, .25, 5
NOTE: ON SOLDER SIDE OF PCB, CONNECT A 27KOHM
RESISTOR AT THE FOLLOWING LOCATIONS:
A) SILKSCREEN SIDE R18 TO SILKSCREEN SIDE R14
B) SILKSCREEN SIDE R19 TO SILKSCREEN SIDE R13
5 4 RC07GF103J RESISTOR, CF, 10K, .25, 5
NOTE: ON COMPONENT SIDE OF PCB, CONNECT A
10KOHM RESISTOR FROM SILKSCREEN SIDE R11 TO
OPPOSITE SILKSCREEN SIDE R13. R16,17,21
6 1 RC07GF563J RESISTOR, CF, 56K, .25, 5 R20
7 1 RC07GF105J RESISTOR, CF, 1M, .25, 5
NOTE: ON COMPONENT SIDE ADD A 1 MEGA-OHM
RESISTOR FROM SILKSCREEN SIDE R8 TO OPPOSITE
SILKSCREEN SIDE C2.
8 1 RC07GF106J RESISTOR, CF, 10M, .25, 5 R7
9 1 RC20GF472J RESISTOR, CF, 4.7K, .5, 5 R3
10 2 RC20GF512J RESISTOR, CF, 5.1K, .5, 5 R1,2
11 2 RC20GF393J RESISTOR, CF, 39K, .5, 5
NOTE: ON COMPONENT SIDE OF PCB, ADD A 39KOHM
RESISTOR AT THE FOLLOWING LOCATIONS:
A) SILKSCREEN SIDE R4 TO SILKSCREEN SIDE R18
B) SILKSCREEN SIDE R5 TO SILKSCREEN SIDE R19
