J12, J13 Jumpers
Installing a burg jumper on J12 will place in service a 112 ohm line-to-line terminator across the receiver
line (RXD, RXD RTN). If the system is subject to extremely noisy environments, it would be better to
terminate only the receiver side of the communication line by line-to-ground termination on each side of
the receiver line (RXC, RXD RTN). Installing burg jumpers on both J12 and J13 will terminate each side
of the receiver line through 56 ohm to ground.
6.7
J14, J15 Jumpers
Installing a burg jumper on J14 will place in service a 112 ohm line-to-line terminator across the receiver
line (TXC, TXC RTN). Installing burg jumpers on both J14 and J15 will terminate each side of the
transmitter line through 56 ohm to ground.
7.0
SWITCH SETTINGS
Position 1 to 5 of SW2 are for setting the MUX numbers and they are set as follows:
MUX NUMBER
SW2-5
SW2-4
SW2-3
SW2-2
SW2-1
MUX 01
OFF
OFF
OFF
OFF
OFF
MUX 02
OFF
OFF
OFF
OFF
ON
MUX 03
OFF
OFF
OFF
ON
OFF
MUX 04
OFF
OFF
OFF
ON
ON
MUX 05
OFF
OFF
ON
OFF
OFF
MUX 06
OFF
OFF
ON
OFF
ON
MUX 07
OFF
OFF
ON
ON
OFF
MUX 08
OFF
OFF
ON
ON
ON
MUX 09
OFF
ON
OFF
OFF
OFF
MUX 10
OFF
ON
OFF
OFF
ON
MUX 11
OFF
ON
OFF
ON
OFF
MUX 12
OFF
ON
OFF
ON
ON
MUX 13
OFF
ON
ON
OFF
OFF
MUX 14
OFF
ON
ON
OFF
ON
MUX 15
OFF
ON
ON
ON
OFF
MUX 16
OFF
ON
ON
ON
ON
MUX 17
ON
OFF
OFF
OFF
OFF
MUX 18
ON
OFF
OFF
OFF
ON
MUX 19
ON
OFF
OFF
ON
OFF
MUX 20
ON
OFF
OFF
ON
ON
MUX 21
ON
OFF
ON
OFF
OFF
MUX 22
ON
OFF
ON
OFF
ON
MUX 23
ON
OFF
ON
ON
OFF
MUX 24
ON
OFF
ON
ON
ON
MUX 25
ON
ON
OFF
OFF
OFF
MUX 26
ON
ON
OFF
OFF
ON
MUX 27
ON
ON
OFF
ON
OFF
MUX 28
ON
ON
OFF
ON
ON
MUX 29
ON
ON
ON
OFF
OFF
MUX 30
ON
ON
ON
OFF
ON
MUX 31
ON
ON
ON
ON
OFF
MUX 32
ON
ON
ON
ON
ON
