Ronan X120 - Manual (Page 20)

7 2 RC07GF102J RESISTOR, CF,1K,.25,5 R4,5
8 1 RC07GF152J RESISTOR, 1/4W, 5%, 1.5K R1
9 1 7200-25 INDUCTOR R2
10 1 RC42GF820J RESISTOR, CF,82,2,5 R7
11 1 RN55C5112F RESISTOR, MF, 51.1K, .125, 1 R3
12 1 101R501M05 CAPACITOR, RAD, MIC, 100P, 500 C3
13 2 105R500C20 CAPACITOR, RAD,CERAMIC,1M C1,5
14 1 104A101C20 CAPACITOR, AXIAL,CERAMIC,.1M,100 C2
15 1 503R501C20 CAPACITOR, RAD,CER,0.5M,500 C7
16 1 685R350T10 CAPACITOR, RAD,TAN,6.8M,35 C6
17 1 157A250E28 CAPACITOR, AXIAL,ELE,150M,25 C4
18 2 1N457A DIODE, SIG,60,150M D2,3
19 2 1N4937 DIODE, REC,600,1 D4,5
20 2 1N4005 DIODE, REC,600,1 D6,7
21 1 1N963B DIODE, ZENER,.4,12,10M D1
22 1 MBR160 DIODE, SCHOTTKY D9
23 2 RFL4N12 TRANSISTOR Q1,2
24 2 2260R HEATSINK ON Q1,2
25 1 CD4047B IC, BUF,MULTIVIB,LOW,PWR U1
26 1 CD4041UBE IC, BUF,TRUE,COMP,GT,QUAD U2
27 1 LM7805CT VOLTAGE REGULATOR 5V TO –220 REG1
28 1 HLMP-3300 LED, RED,HI,.198 LED1
29 1 RY-6WZ-K or
T82S11D114-05 or
G5V-2-DC6 RELAY K1
30 1 X120B25-4 TRANSFORMER, DC/DC T1
31 2 05JUMPERS JUMPER, .5,.125,22AWG,PVC J1,3
32 1 6072B HEATSINK
33 1 0440X0086PHPHM
S SCREW, 4-40X1/4 PHIL,PAN,MS FOR REG1
34 1 4-40 SM PATTERN NUT, SMALL PATTERN FOR REG1
35 1 4-INT-L/W WASHER, INTERNAL LOCK FOR REG1
X120-LPS-48 Power Supply
Item Qty Part Number Description I.D.
1 1 X120-1002B PCB
2 1 CP66 CARD EJECTOR
3 1 7101P4D9AQE SWITCH, TOGGLE, PCB, SPDT S1
4 1 312.500 FUSE F1
5 2 3529 FUSE HOLDER
6 1 RC07GF471J RESISTOR, CF,470,.25,5 R6
7 2 RC07GF100J RESISTOR, CF,10,.25,5 R4,5
8 1 UT-2A 20 OHM 5% RESISTOR, PWR,WW,2.5 R2
9 1 RC42GF820J RESISTOR, CF,82,2,5 R7
10 1 RC32GF392J RESISTOR, CF,3.9K,1,5 R1
11 1 RN55C5112F RESISTOR, MF,51.1K,.125,1 R3
12 1 101R501M05 CAPACITOR, RAD,MIC,100P,500 C3
13 1 105R500C20 CAPACITOR, RAD,CERAMIC,1M C5
14 1 104A101C20 CAPACITOR, AXIAL,CER,.1M,100 C2
15 1 503R501C20 CAPACITOR, RAD,CER,0.5M,500 C7
16 1 685R350T10 CAPACITOR, RAD,TAN,6.8M,35 C6
17 1 157A250E28 CAPACITOR, AXIAL,ELE,150M,25 C4
18 1 503R501C20 CAPACITOR, RADIAL,CER,.05M,500 C1
19 2 1N457A DIODE, SIG,60,150M D2,3
