Ronan X120 - Manual (Page 18)

25 1 T82P11D11424VD
C RELAY, GP,PCB,24DC,DPDT K1
26 1 X120B25-6 TRANSFORMER, DC/DC T1
27 2 05JUMPERS JUMPER, .5,.125,22AWG,PVC J2,3
X120-FCPS12524 Power Supply
Item Qty Part Number Description I.D.
1 1 X120-1002B PCB
2 1 CP66 CARD EJECTOR
3 1 7101P4D9AQE SWITCH, TOGGLE, PCB, SPDT S1
4 1 312.150 FUSE, .15A F1
5 2 3529 FUSE HOLDER
6 3 NOT USED COMPONENTS NOT USED C6,J1,R6
7 2 RC07GF100J RESISTOR, CF, 10, .25, 5 R4,5
8 1 UT-2A 50 OHM 5% RESISTOR, PWR/WW/2.5 R2
9 1 NOTE: USE BUSS WIRE FOR R7.
10 1 RC42GF273J RESISTOR, CF,27K,2,5 R1
11 1 RN55C5112F RESISTOR, MF, 51.1K, .125, 1 R3
12 1 101R501M05 CAPACITOR, RAD, MIC, 100P, 500 C3
13 1 104A101C20 CAPACITOR, AXIAL, CER, .1M, 100 C2
14 3 503R501C20 CAPACITOR, RADIAL, CER, .05M, 500 C1,5,7
15 1 156A400E28 CAPACITOR, AXIAL, ELE, 15M, 40 C4
16 2 1N457A DIODE, SIG, 60, 150M D2,3
17 2 1N4937 DIODE, REC, 600, 1 D4,5
18 2 1N4005 DIODE, REC, 600, 1 D7,8
19 1 1N963B DIODE, ZENER, .4, 12, 10M D1
20 2 VN0350N2 TRANSISTOR Q1,2
21 2 2260R HEATSINK ON Q1,2
22 1 CD4047BE IC, BUF, MULTIVIB, LOW, PWR U1
23 1 CD4041UBE IC, BUF, TRUE, COMP, GT, QUAD U2
24 1 HLMP-3300 LED, RED, HI, .198 LED1
25 1 T82N11D114-24V RELAY K1
26 1 X120B25-3 TRANSFORMER, DC/DC T1
27 2 05JUMPERS JUMPER, .5,.125,22AWG,PVC J2,3
X120-FCPS125125 Power Supply
Item Qty Part Number Description I.D.
1 1 X120-1002B PCB
2 1 CP66 CARD EJECTOR
3 1 7101P4D9AQE SWITCH, TOGGLE, PCB, SPDT S1
4 1 312.150 FUSE .15A F1
5 2 3529 FUSE HOLDER
6 6 NOT USED COMPONENTS NOT USED C6, D6, D9, J1,
R6, VR1
7 2 RC07GF100J RESISTOR, CF, 10, .25, 5 R4,5
8 1 UT-2A 50 OHM 5% RESISTOR, PWR,WW,2.5 R2
9 1 UT-2A 7KOHM 5% RESISTOR, PWR,WW,2.5 R7
10 1 RC42GF273J RESISTOR, CF,27K,2,5 R1
11 1 RN55C5112F RESISTOR, MF, 51.1K, .125, 1 R3
12 1 101R501M05 CAPACITOR, RAD, MIC, 100P, 500 C3
13 1 104A101C20 CAPACITOR, AXIAL, CER, .1M, 100 C2
14 3 503R501C20 CAPACITOR, RADIAL, CER, .05M, 500 C1,5,7
15 1 475A251E28 CAPACITOR, AXIAL, ELE, 4.7M,250 C4
16 2 1N457A DIODE, SIG, 60, 150M D2,3
