12 2 1.5KOHM5W RESISTOR, POWER WW
NOTE: CONNECT RESISTORS AT R18,19 SO THAT TOP OF
RESISTORS ARE LEVEL WITH TOP OF RELAY AT K1 R18,19
13 2 103A101C10 CAPACITOR, AXIAL, CERAMIC, .01M C1,2
14 2 1N4148 DIODE, SIGNAL, 75V, 400M CR1,2
15 1 1N4005 DIODE, REC, 600, 1 CR4
16 1 1N5359B DIODE, ZENER, 5, 24, 50M CR3
17 2 RC07GF1RJ RESISTOR, CF, 1, .25, 5
NOTE: ON COMPONENT SIDE OF PCB, ADD A ONE OHM
RESISTOR FROM SILKSCREEN SIDE R12 TO OPPOSITE
SILKSCREEN SIDE OF R14. CR5
18 1 HLMP-3001 LED, RED, STANDARD, .19 POWER
19 2 HLMP-1300 LED, RED, STANDARD LED1,2
20 1 2N4249 TRANSISTOR, PNP, 60, 92 Q1
21 1 2N3568-5 TRANSISTOR, NPN, 60 , 92 Q2
22 1 T82S11D11424VD
C RELAY, GP, PCB, 24DC, DPDT K1
23 1 CP66 CARD EJECTOR PCB
24 1 1N270 DIODE, SIGNAL
NOTE: ON COMPONENT SIDE ADD A 1N270 DIODE FROM
PIN 4 U1 (ANODE) TO OPPOSITE SILKSCREEN R8
(CATHODE)
25 1 106A350E28 CAPACITOR, AXIAL, ELE, 10M, 35
NOTE: CONNECT CAPACITOR FROM R1,2 SOLDER PAD
(POSITIVE) TO POSITION OPPOSITE OF SILKSCREEN R3
(NEGATIVE). COVER EXPOSED LEADS WITH 22 AWG
TEFLON TUBING. FOR ALL COMPONENT ADDITIONS,
COVER EXPOSED LEADS WITH 22 AWG TEFLON
TUBING. C3
X120-FCPS2424 Power Supply
Item Qty Part Number Description I.D.
1 1 X120-1002B PCB
2 1 CP66 CARD EJECTOR
3 1 7101P4D9AQE SWITCH, TOGGLE, PCB, SPDT S1
4 1 312.500 FUSE F1
5 2 3529 FUSE HOLDER
6 3 NOT USED COMPONENTS NOT USED C6,J1,R6
7 2 RC07GF100J RESISTOR, CF, 10, .25, 5 R4,5
8 1 RC07GF152J RESISTOR, CF, 1.5K, .25, 5 R1
9 1 RC20GF180J RESISTOR, CF, 18, .5, 5 R2
10 1 02JUMPER JUMPER R7
11 1 RN55C5112F RESISTOR, MF, 51.1K, .125, 1 R3
12 1 101R501M05 CAPACITOR, RAD, MIC, 100P, 500 C3
13 1 104A101C20 CAPACITOR, AXIAL, CER, .1M, 100 C2
14 3 503R501C20 CAPACITOR, RADIAL, CER, .05M, 500 C1,5,7
15 1 156A400E28 CAPACITOR, AXIAL, ELE, 15M, 40 C4
16 2 1N457A DIODE, SIG, 60, 150M D2,3
17 2 1N4937 DIODE, REC, 600, 1 D4,5
18 2 1N4005 DIODE, REC, 600, 1 D7,8
19 1 1N963B DIODE, ZENER, .4, 12, 10M D1
20 2 VN0109N2 FET, N, MOS, 90 TO 39 Q1,2
21 2 2260R HEATSINK ON Q1,2
22 1 CD4047BE IC, BUF, MULTIVIB, LOW, PWR U1
23 1 CD4041UBE IC, BUF, TRUE, COMP, GT, QUAD U2
24 1 HLMP-3300 LED, RED, HI, .198 LED1
