X120-1001-230 Input Logic Module
Item
Qty
Part Number
Description
I.D.
1
1
X120-1001C
PCB
2
288
1N4005
DIODE, REC\600\1
CR1-6
3
48
6N139
IC, ISOLATOR\OPTICAL
U1-48
4
48
RC07GF105J
RESISTOR, CF\1M\.25\5
R1
5
96
RC20GF153J
RESISTOR, CF\15K\.5\5
R2,3
6
54
104A101C20
CAPACITOR, AXIAL\CER\.1M\100
C1-54
7
6
4310R-101-103
RESISTOR, NETWORK SIP COM 10K
RP1,4,5,8,9,12
8
6
898-3-R100K
RESISTOR, NETWORK\DIP\IND\100K
RP2,3,6,7,10,11
9
6
74HC240N
IC, CMOS\INVERTER\TRI-STATE\8
U49-54
10
2
T83S11D112-5VDC
RELAY, GP\PCB\5DC\DPDT
K1,2
11
2
1N4148
DIODE, SIG\74V\400M
CR7,8
12
192
CA36SP100230430
PLUG, STRIP\LINE\36 PINS
NOTE: STRIP OF 2
B,C
13
1
291-0003
CONNECTOR, PCB\EDGE\18
J1
14
4
1731035
TERMINAL BLOCK, PCB 3 POINT
TB1-4
15
192
531220-2
SHUNT 2 PIN
B,C
16
1
1731022
TERMINAL BLOCK, PCB, 2 POINT
TB5
17
48
DILB08P-11T
SOCKET, IC
U1-48
18
1
V275LA20A
VARISTOR, 369\OPR\VOLT
V1
19
4
7002922
CONNECTOR
TBA,TBB,
TBC,TBD
20
4
7002922
CONNECTOR
TBA, TBB, TBC,
TBD
21
2
03JUMPERS
JUMPER, .3\.125\22AWG\PVC
J1,2
X120-1001-125 Input Logic Module
Item
Qty
Part Number
Description
I.D.
1
NOTE: IDENTIFY BOARD PER X120-1001-125VDC/115VAC
2
1
X120-1001C
PCB
3
288
1N4005
DIODE, REC\600\1
CR1-6
4
48
6N139
IC, ISOLATOR\OPTICAL
U1-48
5
48
RC07GF105J
RESISTOR, CF\1M\.25\5
R1
6
96
RC20GF623J
RESISTOR, CF\62K\.5\5
R2,3
7
54
104A101C20
CAPACITOR, AXIAL\CER\.1M\100
C1-54
8
6
4310R-101-103
RESISTOR, NETWORK SIP COM 10K
RP1,4,5,8,9,12
9
6
898-3-R100K
RESISTOR, NETWORK\DIP\IND\100K
RP2,3,6,7,10,11
10
6
74HC240N
IC, CMOS\INVERTER\TRI-STATE\8
U49-54
11
2
T83S11D112-5VDC
RELAY, GP\PCB\5DC\DPDT
K1,2
12
2
1N4148
DIODE, SIG\74V\400M
CR7,8
13
192
CA36SP100230430
PLUG, STRIP\LINE\36 PINS
NOTE: STRIP OF 2
B,C
14
1
291-0003
CONNECTOR, PCB\EDGE\18
J1
15
4
1731035
TERMINAL BLOCK, PCB 3 POINT
TB1-4
16
192
531220-2
SHUNT 2 PIN
B,C
17
1
1731022
TERMINAL BLOCK, PCB, 2 POINT
TB5
18
48
DILB08P-11T
SOCKET, IC
U1-48
19
1
V275LA20A
VARISTOR, 369\OPR\VOLT
V1
20
4
7002922
CONNECTOR
TBA,TBB,
TBC,TBD
20
4
7002922
CONNECTOR
TBA, TBB,
TBC, TBD
21
2
03JUMPERS
JUMPER, .3\.125\22AWG\PVC
J1,2
