Table 2 - pneumatic connections – Ransburg PulseTrack2 A11515-XXXXX User Manual
Page 19

Factory Air (clean and dry)
Rotator 1 Volume Booster Pilot
Rotator 2 Volume Booster Pilot
Rotator 3 Volume Booster Pilot
Rotator 4 Volume Booster Pilot
Rotator 5 Volume Booster Pilot
Rotator 6 Volume Booster Pilot
Rotator 1 Enable Air Source
Rotator 2 Enable Air Source
Rotator 3 Enable Air Source
Rotator 4 Enable Air Source
Rotator 5 Enable Air Source
Rotator 6 Enable Air Source
Rotator 1 Brake Valve Assy. Pilot
Rotator 2 Brake Valve Assy. Pilot
Rotator 3 Brake Valve Assy. Pilot
Rotator 4 Brake Valve Assy. Pilot
Rotator 5 Brake Valve Assy. Pilot
Rotator 6 Brake Valve Assy. Pilot
TABLE 2 - PNEUMATIC CONNECTIONS
From
Supply
CL1
CL2
CL3
CL4
CL5
CL6
EN1
EN2
EN3
EN4
EN5
EN6
BR1
BR2
BR3
BR4
BR5
BR6
To
Supply Air to PulseTrack 2
Rotator 1 Transducer Output Control Signal
Rotator 2 Transducer Output Control Signal
Rotator 3 Transducer Output Control Signal
Rotator 4 Transducer Output Control Signal
Rotator 5 Transducer Output Control Signal
Rotator 6 Transducer Output Control Signal
Rotator 1 Speed Control Interlock
Rotator 2 Speed Control Interlock
Rotator 3 Speed Control Interlock
Rotator 4 Speed Control Interlock
Rotator 5 Speed Control Interlock
Rotator 6 Speed Control Interlock
Rotator 1 Brake Output Control Signal
Rotator 2 Brake Output Control Signal
Rotator 3 Brake Output Control Signal
Rotator 4 Brake Output Control Signal
Rotator 5 Brake Output Control Signal
Rotator 6 Brake Output Control Signal
Description
