Ransburg Test Stand RMA-303, EVOLVER, EVOLVER NE User Manual
Page 13
LN-9259-07.1
2. Fluid enable off (toggle switch lever in the
down position).
3. Attach the applicator to the Test Stand bracket
with three (3) M10 screws (78268-00).
4. Connect tubing from the Test Stand to the ap-
plicator as labeled.
5. Supply 100 psig air pressure to the stand,
reference supply air gauge on panel. If required,
adjust air input regulator attached to stand.
6. Set speed select to 00.
7. Adjust bearing air regulator to 90 psig mini-
mum.
100
Test Stations - Operation
10
