Troubleshooting Error Codes
Cannot Zero During ‘S-00’
in ‘Set’
The Reflector was not
covered or the Detector was
not aligned onto the Reflector.
• Ensure Reflector was
completely covered with a
non-reflective material
• Re-align Detector using
Auto-Align
No Signal During ‘S-01’ in ‘Set’
The Reflector was not uncovered
during ‘S-01’.
• Ensure Reflector was
uncovered when ‘S-01’ was
selected
‘Centre’ Stage of Alignment
Failed
Detector has aligned on
something other than the
Reflector
• Ensure clear line of sight from
Detector to Reflector for a
radius of 0.5m
19
