Commissioning
Alignment Status
10. System is Aligned
• It is recommended to set the system back to ‘Lo A’ mode
• Green LED on Detector will flash every 10 seconds, and
Signal Strength should be between 99% and 101%
• Default values: 35% Fire Threshold, 10 second delay to
Fire and Fault, Non-Latching mode
• Refer to User Guide page 13-14 to change settings and
for Fire and Fault Test
11. Check Alignment Status Displays
A commissioned
system will display:
When Detectors have
been found but the
selected Detector is not
aligned the system will
display:
When a Detector is
connected but not
‘Found’ the system will
display:
12
