The system will signal Fault while in this mode
The LASER is used to align the Detector with the Reflector. It
is an approximate alignment tool only. After Auto-Align the
LASER will not necessarily be pointing on the Reflector
• Use to move the LASER as close to the
Reflector as possible
• One press of an arrow key results in one movement of the
Detector head
• Press or to turn off the LASER and return to the
Settings menu
• Refer to User Guide page 20 for troubleshooting if LASER
is not visible
LASER Targeting
Commissioning
LASER RADIATION - AVOID
DIRECT EYE EXPOSURE
POWER OUTPUT < 5mW
CLASS IIIa LASER
Wavelength 630 - 680 nm
DANGER
7. LASER Targeting
10
