CLASS 2000 METER
62-0389-05 48
Modem Interface Cable: UL-listed Telephone Cord,
6-cond. 300 VAC, Stranded
Cond. 22-26 AWG.
Cable Connector: RJ-45 male IDC
Input/Output Voltage: +5 VDC/18 VAC
Ckt Input Isolation 5.3K VAC for 1 Minute
Baud Rate: 9600
IDR Interface Port Cable: UL-listed/rated Telephone
Cord. 4-cond.
Input/output Voltage: Ground-isolated +/-5.4VDC
Cable Connector: RF-45 Male IDC Or Screw
Terminal Termination
Circuit Input Isolation: 5.3kVAC
Circuit output Isolation: 21.5kVAC
Isolated Pulse/Alarm Outputs
(TB5, TB6):
Output Voltage Potential:
0 VDC to +5 VDC Logic Levels
Mating Plug Connector: Weidmuller PN: 152876
Signal Isolation Voltage: 5.3K VAC for 1 Minute
Recommended
In-line Fuse
Manufacturer: Littlefuse
Mfg. Part No: KLDR.100
Rating: 100mA, Time-delay, 600VAC
Cartridge Fuse
Battery Cell Description: Non-rechargeable Cell Used
For Memory Retention
Manufacturer: Eagle-Picher
Mfg Part No: LTC-3PN-S2
Working Voltage: 3.5VDC
Current Capacity 350mAhr
Electrolyte: Lithium Thionyl Nitrate
