CLASS 2000 METER
62-0389-05 4
1.0 PRE-INSTALLATION INFORMATION
The E-Mon D-Mon® Class 2000 kWh/Demand meter is a 3-element meter used to
monitor electric power usage of individual loads after the utility meter . Installation
must only be performed by qualified personnel and in accordance with these
instructions and all applicable local and national electrical codes. E-Mon or its
representatives assume no responsibility for damages or injury resulting from the
improper installation of this meter.
Meters are supplied in a UL Type 1 steel enclosure appropriate for indoor installation
where it will not be affected by the elements, such as moisture and extreme
temperatures.
Units designated by the “R” suffix on the model number have an extended
environmental operating range and are enclosed in a NEMA 4X enclosure to
accommodate outdoor environments.
Verify the input voltage rating and configuration on the meter label to ensure it is
suitable for the intended electrical services. For example, Class 2000 meters labeled
for 208V service MUST NOT be installed on service feeds of 480V and vice versa.
Verify the current sensors are sized suitably for the load to be monitored. Compare the
color of the arrows on the current sensors to the chart below to confirm the correct
current sensor is being used.
Sensor Arrow Color Code Sensor Rating
Brown 100 Amp
Red 200 Amp
Yellow 400 Amp
Black 800 Amp
Blue 1600 Amp
White/Black 3200 Amp
Meter Labeled: Works On:
120/240V 120/240V, 1 Phase
208V 208V, 3 Phase
240V 240V, 3 Phase
400V (380, 415) 400V, 3 Phase
480V 480V, 3 Phase
600V 600V, 3 Phase
