Installation PEM-9004
Teledyne Analytical Instruments 14
•
Connect the gas out port to a suitable vent.
WARNING: TOXIC AND FLAMMABLE GASES ARE PRESENT IN
THIS INSTRUMENT. THESE GASES CAN BE
HARMFUL AND/OR FLAMMABLE EVEN AT LOW
CONCENTRATIONS. THE ANALYZER’S EXHAUST
PORT MUST BE VENTED TO A SAFE AREA.
PERSONAL PROTECTIVE EQUIPMENT MUST BE
WORN WHEN USING OR SERVICING THIS
INSTRUMENT.
AFTER EACH USE, BEFORE TURNING OFF THE
POWER OR DISCONNECTING ANY TUBING
CONNECTED TO THE ANALYZER, REMOVE THE
PROBE AND FLUSH THE UNIT WITH AIR FOR FIVE
MINUTES
Figure 3-1: PEM-9004 Front Panel
3.3 Initial Calibration
The instrument, when first powered up will go through a self-
diagnostic test routine and auto calibrate. For this reason, when
