iv
Model 3000PB
Teledyne Analytical Instruments
3.3.9 Remote Sensor and Solenoid Valves ..................... 3-10
3.4 Installing the Micro-Fuel Cell .......................................... 3-12
3.5 Gas Connections ........................................................... 3-12
3.6 Testing the System ........................................................ 3-14
4 Operation
4.1 Introduction .................................................................... 4-1
4.2 Using the Data Entry and Function Buttons ................... 4-2
4.3 The System Function ..................................................... 4-3
4.3.1 Setting the Display ................................................. 4-4
4.3.2 Setting up an Auto-Cal ........................................... 4-5
4.3.3 Password Protection .............................................. 4-5
4.3.3.1 Entering the Password ................................... 4-6
4.3.3.2 Installing or Changing the Password ............. 4-7
4.3.4 Logout .................................................................... 4-8
4.3.5 System Self-Diagnostic Test .................................. 4-9
4.3.6 Version Screen ...................................................... 4-9
4.4 The Span Functions ....................................................... 4-10
4.4.1 Cell Failure ............................................................. 4-10
4.4.2 Span Cal ................................................................ 4-11
4.4.2.1 Auto Mode Spanning ..................................... 4-11
4.4.2.2 Manual Mode Spanning ................................. 4-12
4.5 The Alarms Function ...................................................... 4-12
4.6 The Range Function ...................................................... 4-15
4.6.1 Setting the Analog Output Ranges ........................ 4-15
4.6.2 Autoranging Analysis ............................................. 4-16
4.6.3 Fixed Range Analysis ............................................ 4-16
4.7 The Analyze Function .................................................... 4-17
4.8 Signal Output ................................................................. 4-17
Maintenance
5.1 Routine Maintenance ..................................................... 5-1
5.2 Major Internal Components ........................................... 5-1
5.3 Cell Replacement .......................................................... 5-2
5.3.1 Storing and Handling Replacement Cells ............... 5-3
5.3.2 When to Replace a Cell ........................................... 5-3
5.3.3 Removing the Micro-Fuel Cell ................................. 5-4
5.3.4 Installing a New Micro-Fuel Cell .............................. 5-6
5.3.5 Cell Warranty ........................................................... 5-6
5.4 Fuse Replacement ......................................................... 5-7
5.5 System Self Diagnostic Test........................................... 5-7
5.6 LCD Display ................................................................... 5-8
