4 Operation Model 2000A-EU
4-10 Teledyne Analytical Instruments
Power: OK Analog: OK
Cell: 2 Preamp: 3
The module is functioning properly if it is followed by
OK. A number
indicates a problem in a specific area of the instrument. Refer to Chapter 5
Maintenance and Troubleshooting for number-code information. The results
screen alternates for a time with:
Press Any Key
To Continue...
Then the analyzer returns to the initial System screen.
4.3.6 The Model Screen
Move the < > arrow key to
MORE and press
Enter . With
MODEL
blinking, press Enter . The screen displays the manufacturer, model, and soft-
ware version information.
4.3.7 Checking Linearity with ALGORITHM
From the System Function screen, select
ALGORITHM, and press
Enter .
Range linearization
—> Ш1 Ш2 Ш3 <—
Use the < > keys to select the range: 01, 02, or 03. Then press Enter .
Range: Ø —16 %
Gas use: O2 — N2
Press Enter again.
Algorithm setup:
VERIFY SET UP
Select and Enter
VERIFY to check whether the linearization has been
accomplished satisfactorily.
Dpt INPUT OUTPUT
Ш Ш.ШШ Ш.ШШ
The leftmost digit (under
Dpt) is the number of the data point being moni-
tored. Use the
∆∇
keys to select the successive points.
The
INPUT value is the input to the linearizer. It is the simulated output of
the analyzer. You do not need to actually flow gas.
