Thermal Conductivity Analyzer Installation 3
3-1
Installation
Installation of the Model 2000A Analyzer includes:
1. Unpacking
2. Mounting
3. Gas connections
4. Electrical connections
5. Installing the Sensor
6. Testing the system.
3.1 Unpacking the Analyzer
The analyzer is shipped ready to install and prepare for operation.
Carefully unpack the analyzer and inspect it for damage. Immediately
report any damage to the shipping agent.
The four gas fittings that mate with the 1/8 NPT gas ports on the
Model 2000A, are not included. They must be supplied by the customer.
3.2 Mounting the Analyzer
The Model 2000A is for indoor use in a general purpose area. It is
NOT for hazardous environments of any type. It must be protected from:
• Direct sunlight
• Drafts of air
• Shock and vibration
• Temperatures below 30 °F (-1 °C) or above 110 °F (43 °C).
Locate the 2000A as close as possible, subject to the above conditions,
to the sample point to minimize effects of sample line lag time on the
analysis.
The standard model is designed for flush panel mounting. Figure 3-1 is
an illustration of the 2000A standard front panel and mounting bezel. There
