012-03800A
Figure 5a
Figure 5b
a
b
c
d
e
f
g
b
h
PASCO
Manual
Your SF-8616 Basic Coils Set comes with the items shown in Figure 5a:
a. (1) SF-8609 200-turn Coil
b. (2) SF-8610 400-turn Coils
c. (1) SF-8611 800-turn Coil
d. (1) SF-8614 U-shaped Core
e. (1) Manual
Your SF-8617 Complete Coils Set comes with all of the items in the SF-8616 Basic Coils Set along with the following
additional items, as shown in Figure 5b:
f. (1) SF-8612 1600-turn Coil
g. (1) SF-8613 3200-turn Coil
h. (2) SF-8615 E-shaped Core
Equipment Supplied
