Operation Operating instructions
6-10 HCH5011 / 001
6.4 Working with the Chain saw HCH5011
Following the preparatory operations, see “Chapter 6” 6.3, 6-5 the Chain
saw HCH5011 is ready for use.
6.4.1 Areas of use
The Chain saw HCH5011 is suited to the following cutting work:
• Small cutouts / cutting throughs
• Flush cuttings
• Narrow corner cuts
• Irregular shaped cuts
6.4.2 Starting the Chain saw HCH5011
Always proceed as follows:
• Start the drive assembly (see Operating instructions for the drive you are
using).
• Open the water valve on the drive assembly and check the water outlet
on the Chain saw HCH5011.
• Set the required operating pressure.
– Maximum flow 45 l/min.
– Max. pressure 140 bar
• Hold the Chain saw HCH5011 securely with both hands
• Press the locking cut-out and operate the manual starter
• Check the direction of travel of the chain (if this direction of travel of the
chain is wrong, connect the Chain saw HCH5011 properly).
• Perform the desired cut
6.4.3 Cutting sequence
Begin the cutting work taking into account the instructions of “Chapter 6”,
Position and sequence of cuts 6.3.4,
6-6.
Information
The water outlet on the Chain saw HCH5011 is released by pressing the
locking cut-out and the manual starter.
