ULTIMATE DRILLING MACHINE ELECTRICAL OUTLET BOX
ITEM NUMBER PART NUMBER DESCRIPTION QUANTITY
1 4645127 Electrical Box 1
3 4648047 Front Mount Bracket 1
4 2800858 20 AMP Circuit Breaker 1
5 2800859 40 AMP Circuit Breaker 1
7 2900017 #10-24 Lock Nut 4
8 2900009 ¼” SAE Flat Washer 2
9 2900416 ¼”-20 x ½” Hex Head Tap Screw 1 1
10 2900024 ¼” Split Lock Washer 2
11 2900125 ¼-20 Hex Nut 2
12 2800089 20A 250V Twist lock Receptacle 1
13 2800430 30A 125V Twist lock Receptacle 1
14 2800698 125V GFI Outlet 1
15 2800801 Outlet Cover 1
16 2800791 Outlet Cover 2
17 2800171 ¾” Cord Connector 2
18 2801304 ¾” Lock Nut 2
19 4645135 Cover Plate W/Seal 1
37 1800810 230V Voltage Label 1
38 1801348 115V Voltage Label 2
39 1800415 Diamond Product Label 1
