43
Touring the Software
Sample Lists. Contains a list of protocols, including the version number and the number
of samples associated with each protocol.
Settings. Opens the 3D Settings dialog box. This dialog box has the following options:
• Show Regions
• 3D
• CL1/CL3 Plane
• CL2/CL3 Plane
• CL1/CL2 Plane
• Show Beads
• 3D
• CL1/CL3 Plane
• CL2/CL3 Plane
• CL1/CL2 Plane
• Display Mode
• Logarithmic
• Linear
• Display Position
• 3D View
• CL1/CL3 View
• CL2/CL3 View
• CL1/CL2 View
• View
• All Events
• Gated Events
• Show Cursors
• Show Region Labels
• Show 3D Region View Box
These settings are also available by right-clicking in the applicable sections of the main 3D
display.
All Regions. Displays all regions of the batch.
2D. Returns to the default display.
Default. Returns to the histogram and dot plot display.
Saved Batches Tab
Use this tab to open a batch that has been run, and view its details, export, approve, or
replay a batch.
