Patriot 10:1 Adhesive System Operations Manual
Rev. 03/2014 Page | 38
Part Drawings:
ASSEMBLY DRAWING
PAT-CCP-LS-0590-SS
CHOP CHECK FLUID SECTION ASSEMBLY
PAT-RA-5021-EPDM FOLLOWER PLATE ASSEMBLY
PAT-RA-5000-M RAM ASSEMBLY
– MOBILE
PAT-RA-5000 RAM ASSEMBLY
PAT-MA-11 LOWER AIR MANIFOLD ASSEMBLY
25215-MA-12 LOWER AIR MANIFOLD ASSEMBLY
PAT-MA-14 UPPER AIR MANIFOLD ASSEMBLY
PAT-MA-15 AIR MANIFOLD ASSEMBLY
– UPPER
25215-MA-16 AIR MANIFOLD ASSEMBLY
– 10:1
25215-CM-5 CATALYST MANIFOLD ASSEMBLY
PAT-FM-1 FLUID MANIFOLD ASSEMBLY
PAT-FT-REG PATRIOT FLUSH TANK REGULATOR
PLV-1000 PRESSURE LIMIT VALVE
SC-2500-C SURGE CHAMBER
– SHORT CYLINDER
6101-01-01 3 GAL FLUSH TANK ASSEMBLY
