Magnum Venus Plastech PATRIOT 10:1 ADHESIVE SYSTEM User Manual
Page 3
Patriot 10:1 Adhesive System Operations Manual
Rev. 03/2014
Page | 3
Table of Contents
TERMS & CONDITIONS OF SALE
4
SAFETY & WARNINGS
6
INTRODUCTION
15
REQUIREMENTS & UNIT ASSEMBLY
16
CONTROLS
19
PRIMING the UNIT
22
MIXING & DISPENSING
26
CHANGING the EMPTY PAIL
28
DAILY START-UP & SHUT-DOWN
30
TESTING & ADJUSTING
31
FLUID SECTION MANUAL
34
POWERHEAD MANUAL
35
DISPENSE HEAD MANUAL
36
HOSES
37
PARTS DRAWINGS
38
REVISION INFORMATION
65
